This hybrid is a selective blend of the best features of the contractor-style table saw and cabinet style table saw. Like the cabinet saw, it has an enclosed cabinet with 4 in. dust port, heavy-duty cast iron trunnions that mount to the cabinet, and plenty of power (with its 2 HP motor) to easily rip through hardwoods or cut dadoes. Like the contractor-style saw, it’s still light enough to move around (it weighs approximately 286 lbs. when fully assembled) and it’s easy on the budget. The fence on this machine is also a hybrid of some of the best features we’ve had on table saws in the last 30 plus years. It has the easy lift-off and simple adjustability of the popular T-shape Shop Fox Classic fence, the rock-solid front locking ability of the Shop Fox Original fence, and the accessory T-slots of the Shop Fox Aluma-Classic fence. To top it all off, this saw features an innovative quick-release blade guard and riving knife system that can be changed in seconds—and it’s prewired to run on an ordinary 120-Volt, 20 Amp circuit. Made in an ISO 9001 Factory.
- Cast-iron table and extension wing
- Included 10 in. x 40 T blade
- Easy lift-off, front locking fence with T-slots
- Quick-release blade guide assembly
- 4 in. dust port
- T-slot miter gauge
- Cast-iron trunnions
Specifications
- Blade Diameter (in.): 10
- Maximum Speed (rpm): 3450
- Blade Speed: 3450
- Horsepower (hp): 2
- Table Tilt Right Max (degrees): 0
- Cordless/ Corded: Corded
- Dust Collection Method: 4 in. Dust Port
- Tools Product Type: Power Tool
- Amperage (amps): 15 A
- Rip Capacity – Left: 16.75
- Blade Location: Centered
- PT Horsepower (Hp): 2
- Table Tilt Left Max (degrees): 45
- Color Family: Multi-Colored
- Included Accessories: Blade Guard System,Blades
- Condition: New
- Power Tool Features: Blade Guard System,Stand Included
- Construction Material: Cast Iron
- Bench & Stationary Tool Type: Table Saw
- Cuts Through: Wood
- Portability: Stationary
- Cord Length (ft.): 6
- Depth Control: Adjustable
- Product Weight (lb.): 286
- Rip Capacity – Right: 31
- Maximum Cut Depth @ 45 Deg.: 2.25
- Maximum Cut Depth @ 90 Deg.: 3.25
- Table Length (in.): 40.5
- Product Height (in.): 35.5
- Product Depth (in.): 40.25
- Table Width (in.): 40.5
- Work Table Surface: 40.5 in. x 40.5 in.
- Product Width (in.): 40.25
