The extruded body comes equipped with 24-inch long, 18 gauge adjustable rails. The scale features a laser etched taper gauge, making the degree markings along the hinge plate easy to read for higher precision. To ensure that you are able to make smooth, high precision, and accurate cuts on a regular basis – the taper jig is marked and can be set in the following degrees: 1”/foot – 4.8 degrees 2”/foot – 9.5 degrees 3”/foot – 14.0 degrees A Truly Versatile Hands-On Application Whether you’re right or left handed, this jig converts. It allows you to set up the jig to work on either side of the saw blade, giving you versatility and the ability to create at your own comfort level while producing amazing results. Heavy Duty Construction Made of premium grade aluminum, this angle cutting jig offers project flexibility with it’s impressive strength-to-weight ratio and lightweight design. Package Includes 24” Extruded Body Ergonomic Handle Steel Stock Holder (foot) w/ screws & nuts Wing Knob w/ lock washer
- INCLUDES: (1) Table Saw Taper Cutting Jig with 24” rails with work stops, ergonomic handle, lock knob and laser etched scale
- FUNCTION: Used as a taper cutting guide for table saws, this easy-to-use woodworking tool helps you to make long rip cuts at angles from 1” per foot (4.8 degrees) or up to 3” per foot (15 degrees)
- VERSATILE: Perfect for making angled cuts, projects that require slight tapers or other woodworking projects such as building kitchen table legs, chairs, wooden racks, wedges, and more
- PREMIUM: Made with a highly durable, yet lightweight aluminum extrusion construction that offers anti-corrosive properties and a high strength-to-weight ratio for heavy duty applications
- FEATURES: Sturdy construction and design with extruded legs with an anodized finish, a tapered handle with a round head and textured finish, plush an improved laser etched 17 gauge steel hinge plate
Specifications
- Material: Aluminum
- Tools Product Type: Power Tool
- Power Tool Accessory Type: Other Accessory
- Color Family: Metallic
- Product Weight (lb.): 1.7 lb
- Ideally Used With: Table Saws
- Product Length (in.): 24.5 in
- Product Height (in.): 1.5 in
- Product Width (in.): 2.75 in
