Ideal Step Drill Bit, 1/4 in. – 1 3/8 in.

IDEAL step drill bits for precise, repetitive drilling through the toughest materials including brass, carbon steel, cast iron, stainless steel, and more. These tough and reliable tools are constructed with a rugged titanium nitride exterior coating for protection, edge retention and corrosion resistance. Each step is gradually blended to ease stepping through hole sizes; reducing the need to keep changing drill bits. Split point design eliminates the need for a starter hole or punch and delivers three times faster starts, saving valuable time. The double-fluted design provides balanced cuts, more cutting surface compared to a single flute design, and cooler operation.

• Titanium nitride coating dramatically extends bit life
• Drills 10 different holes sizes 1/4 in. to 1 3/8 in., Step Increments 1/32 in., Step Thickness 1/16 in. – 1/4 in.
• Split-point design for faster starts
• Unique double-fluted design for balanced cuts and cooler operation
• Shank 1 in. length
• Max operating speed 1500 RPM
• Do not use on hammer drills

Specifications

• Self-Feeding: Yes
• Drill Bit Type(s) Included: Step
• Shank Style: 3-Flat
• Bit Material: Titanium
• Material Application: Aluminum,Cast Iron,Duct/Sheet Metal,Stainless Steel,Steel
• Individual/Set: Individual
• Drill Bit Type: Step
• Assembled Depth (in.): 1.75 in
• Shank Diameter: 3/8 in
• Assembled Width (in.): 1.38 in
• Bit Diameter: 1-3/8 in
• Bit Length (in.): 2.75
• Assembled Height (in.): 1.38 in
